Product Details
Place of Origin: GuangZhou，China
Brand Name: Better
Certification: CE、ISO
Model Number: Better 1600SD-3RT
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Price: USD42000-USD82000per set
Packaging Details: Plastic film
Delivery Time: 45 days
Payment Terms: T/T,D/P,D/A,L/C
Supply Ability: 20 sets per month
Clamping Stroke: |
Variable |
Machine Weight: |
9.6T |
Machine Type: |
Hydraulic, Other |
Power Source: |
Electric/Hydraulic |
Transport: |
By Sea |
Type: |
Vertical |
Automatic: |
Yes |
Clamping Stroke: |
Variable |
Machine Weight: |
9.6T |
Machine Type: |
Hydraulic, Other |
Power Source: |
Electric/Hydraulic |
Transport: |
By Sea |
Type: |
Vertical |
Automatic: |
Yes |
| Specification | Value |
|---|---|
| Clamping Force | 160 tons |
| Size | 1500 × 730 mm |
| Max Mold Size | 720 × 660 mm |
| Min Mold Height | 300 + 50 mm |
| Mold Stroke | 300 mm |
| Max Daylight | 600 + 50 mm |
| Ejector Force | 4 tons |
| Thimble Diameter | Φ25 |
| Ejector Distance (Product) | 130 (100) mm |
| Max Hydraulic Pressure | 140 kg/cm² |
| Cooling Water | 1500-1800 liters/hr |
| Heater Power | 4 kW |
| Motor Power | 22 kW |
| Dimension (L × W × H) | 2.86 × 2.76 × 3.30 m |
| Weight | 9.6 tons |
