| Product Name: | Haisong MA1600 PET Injection Machine | Condition: | New |
|---|---|---|---|
| Screw Diameter: | 45mm | Injection Weight: | 291g |
| Dimension(l*w*h): | 5.07*1.35*1.99M | Weight: | 5.3T |
| High Light: | Haisong PET Preform Making Machine,160 Ton PET Preform Making Machine,Small 160 Ton Injection Moulding Machine |
||
New 160Ton Haisong MA1600 Small PET making Injection Molding Machine with Sevor Motor
Features of injection molding machine:
Machined extrextricity with increased distance between pull rods, central-extricity structure and energy saving servo motor. The machine has low noise, quick response and high precision products. The machine has long service life and stable production. T groove drum and a large number of spare parts, the price is more advantageous.
Characteristics of injection unit:
High quality linear guide ensures smooth and precision of injection molding process. The machine has high speed and high pressure injection structure, which greatly improves the injection speed. There is a double nozzle cylinder to make the structure more uniform and stable. All kinds of appliances have special screw cylinder design.
Features of clamping unit:
Optimized platen design, high rigidity, increase the distance between pull rods. Platen layout based on European map, t-slot and tap hole, mobile platen positioning design, more suitable for all kinds of molds. The machine has a new ejection system design, ejection travel longer, more space, better rigidity. Hydraulic transmission gear die height adjustment mechanism. Mechanical safety interlocking device makes operation more convenient. Front connecting rod The connecting rod structure greatly improves the strength of the connecting rod and the stiffness and accuracy of the whole clamping device.
Machine parameter
| Brand Name | Haisong |
| Model Number | MA1600 |
| Year | 2021 |
| Style | Horizontal |
| Machine Type | Hydraulic |
| Key Selling Points | Energy saving |
| Plastic material | PP, PC, ABS, PET, PVC, HDPE, ABS/PP and so on |
| Applicable Industries | Manufacturing Plant |
| Screw diameter | 45 mm |
| Theoretical Shot Volume | 320 cm³ |
| Injection Rate | 148 g/s |
| Injection Weight | 291 g |
| Distance between Tie Bars | 470*470mm |
| Ejector Stroke | 140 mm |
| Ejector Force | 33 kN |
| Clamping Force | 1600 kN |
| Pump Motor Power | 16 kW |
| Weight | 5.3 T |
| Size | 5.07*1.35*1.99M |
| Warranty | 1 Year |
| After-sales Service Provided | Video technical support, Free spare parts, Online support |
| Place of Origin | China |
The injection molding machine is designed for disposable barrels, chairs, containers etc. It is with demoulding linkage which shorten the plastic parts cycle time. the injection molding machine with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
