Automatic Plastic Injection Molding Machine LSR Type C Connector Precision Assembly

Brand Name:	Better
Model Number:	Better 319
MOQ:	1 SET
Price:	USD17999-USD34999per set
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	30 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

GuangZhou，China

Certification:

CE、ISO

Use Material:

Liquid Silicone Rubber

Volume Ratio %:

1：1

Clamping Way:

Hydraulic

Color:

Gray & Green

Control System:

PLC

Packaging Details:

Wooden case

Highlight:

Precision Plastic Injection Molding Machine

Type C Connector Plastic Injection Molding Machine

LSR injection moulding machine

Product Description

Automatic LSR Type-C Connector Precision Assembly Liquid Silicone Rubber Production Machine

S-guangyu provides integrated solutions including machinery, molds, and support services for manufacturing medical parts with this advanced production system.

Key Features

Independent double-cylinder injection system ensures injection stability and supports different glue types
Independent direct pressure clamping unit accommodates various mold thicknesses
Mechanical positioning device guarantees accurate positioning and mold protection
Flexible independent system design enables single-mode production
Comprehensive range of technical options available

Professional Service Support

Pre-Sale Service

Investment budget and plant planning consultation
Complete machine and mold solutions tailored to customer products

On-Site Service

Installation and new machine debugging services
Complimentary operator and maintenance staff training

After-Sales Service

Timely on-site technical support
Priority upgrade services for existing customers

This liquid silicone injection molding machine employs cold runner technology. After precisely blending the low-temperature liquid A and B components of silicone in the correct ratio, the mixture is pressurized by a screw and injected into the high-temperature mold cavity where rapid chemical cross-linking occurs, achieving high-precision automated production.

Working Principle Flow

1. Raw Material Delivery and Mixing:

Liquid silicone rubber components A (catalyst) and B (cross-linking agent) are conveyed in fixed ratio to a static mixer for thorough blending, with optional colorant additives.

2. Injection Molding:

Mixed liquid silicone is propelled through a cold runner system (preventing premature curing) and rapidly injected into the preheated mold cavity.

3. High-Temperature Vulcanization:

Heated mold initiates rapid chemical cross-linking reaction, transforming liquid silicone into stable elastic products.

4. Pressure Holding and Cooling:

Constant pressure ensures dimensional accuracy before cooling and product removal.

5. Automation Cycle:

Continuous automated production minimizes manual intervention for maximum efficiency.

Comparison with Conventional Injection Molding

Feature	LSR Injection Molding	Conventional Injection Molding
Raw Material State	Liquid components	Solid raw materials
Forming Method	Chemical cross-linking (thermosetting)	Cooling solidification
Temperature Control	Cold runner with heated mold	Heated barrel and mold
