Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design

Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design

    • Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design
    • Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design
    • Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design
    • Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design
  • Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 650S8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 45 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Transportation: Ocean Clamping Force: 6500KN
    Injection Weight: 1966~3072g Opening Stroke: 920mm
    Space Between Tie Bars: 930*900(mm*mm) Energy Saving: Servo

    Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design






    Injection Molding Machine Details



    1. Machine characteristics:
    1. In view of different material and applications we supply variety of screw and barrel for customer choice.
    2. Injection unit adopts linear guide rail built-in carriage cylinder, and integral casting support, thus enhence its rigidity, and make the compact structure.
    3. Increase the speed and saves power from20%~50%depending upon the molding.
    4. Double-carriage cylinder is adopted to ensure stable injection.
    5. New design small volume with high efficient heat exchanger maintains the hydraulic oil temperature stable.
    6. Optimized template design, improve the rigidity and precision of mold open/closing.
    7. Adopt special macromolecule wear part and self lubricating platen guides, can easily adjust the height. Balance the weight, durable and clean.
    8. Latest design invisible and adjustment free mechanical safety interlock device safety and decreases exposure.
    9. Programmable central lubrication system for high efficiency and low maintenance and extended toggle life.
    10. High performance self lubricating graphite impregnated bearing enhances the performance of both toggle and sliding parts. reduction is maintenance cost and time lesser use of lubrication oil and there by decrease in pollution and clean environment.



    2. Electronic control system

    8'' LCD color led screen / 7'' LCD color led screen

    200 groups computer internal storage mould menory function

    Temperature deviation display, thermocouple circuit alarm function

    System hardware I / O detection function

    Reserve a printer interface, floppy port

    Electrica motor safety protection function

    Emergency stop protection function



    3. Parameter of LOG650S8 Machine

    INJECTION LOG650
    A B C
    Shot volume cm³ 2160 2734 3376
    Shot weight (ps) G 1966 2488 3072
    oz 67 87 108
    Max injection rate cm³/s 420 531 656
    Screw diameter Mm 80 90 100
    Plasticizing rate Kg/h 254 340 442
    Injection pressure Mpa 215 170 138
    Screw L:D ratio   22:1 21:1 19.5:1
    screw speed r/min 0~140
    CLAMPING
    Clamping force Kn 6500
    Opening stroke Mm 920
    Platen size MmXmm 1320*1290
    Space between tie bars MmXmm 930*900
    Mold thickness (Min--Max) Mm 350~910
    Hydraulic ejection stroke Mm 265
    Hydraulic ejection force Kn 182
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 22+30
    Heating capacity Kw 38.3
    Number of temp control zones   6+ (nozzle)
    GENERAL
    Dry-cycle time sec 6
    oil tank capacity L 1500
    Machine dimensions Mxmxm 9.6*1.9*2.3
    Machine weight kg 36000



    4. The Machine LOG-650S8 Shipment Detials

    Energy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design





    Here are the right price, first-class quality, professional technical and after-sales service.
    LOG MACHINE, Be absorbed in good future!

    Download The E-catalog NowEnergy Saving Injection Molding Machine 2488G With Hydraulic System And Bridge Style Design
