Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor

Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor

    • Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor
    • Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor
    • Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor
  • Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 500S8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 30 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Computerized: Computerized Transportation: Ocean
    Clamping Force: 5000KN Injection Weight: 1494~2397g
    Opening Stroke: 820mm Space Between Tie Bars: 830*830(mm*mm)
    Special: General Purpose

    Tailor-made availble 500Ton Injection Molding Machine With Components Of Famous Brands




    LOG-500S8 Injection Molding Machine
    1. LOG Machine Advantages



    Servo Drive Feature



    1. Real-time monitor for actual pressure,flow,driver current output ,load rate is implemented by high-speed communication bus.

    2. Medium-large models machine adopts dual-pump or multiple-pump with the way of confluence and special controls to servo system that is achieved with synchronization of controlling servo and oil pump perfectly to reach the confluence of multiple oil pumps.

    3. After the actual test,LOG S8 servo injection molding machine can save 45.5% of power compared with traditional fixed pump injection molding machine,which most energy-saving up to 80%.



    PREFORM SYSTEMS ADVANTAGES



    ■ Low acetaldehyde (A.A) levies for best preform quality.
    ■ Fast and precise for high productivity.
    ■ Compact to save space for your down stream equipment.
    ■ Custom fit to meet your production needs.





    2. LOG 160S8 Machine Parameters:


    INJECTION LOG500
      A B C
    Shot volume cm³ 44 58 73
    Shot weight (ps) G 1385 1810 2290
      oz 1260 1646 2084
    Max injection rate cm³/s 311 406 514
    Screw diameter Mm 70 80 90
    Plasticizing rate Kg/h 82 117 141
    Injection pressure Mpa 217 176 145
    Screw L:D ratio   22:1 20:1 18:1
    screw speed r/min 0~200
    CLAMPING
    Clamping force Kn 5000
    Opening stroke Mm 480
    Platen size MmXmm 745*745
    Space between tie bars MmXmm 510*510
    Mold thickness (Min--Max) Mm 200~550
    Max.daylight Mm 1030
    Hydraulic ejection stroke Mm 150
    Hydraulic ejection force Kn 67
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 18.5
    Heating capacity Kw 13.1
    Number of temp control zones   5+ (nozzle)
    GENERAL
    Dry-cycle time sec 5.1
    oil tank capacity L 820
    Machine dimensions Mxmxm 8.6*1.75*2.35
    Machine weight kg 14970


    3.The Details Show:
    Tailor Made 500 Ton Injection Molding Machine With Real Time Monitor

    Feel hard to find an injection molding machine for specific productions?LOG machine can fulfill your requirement --------custom-tailored ,appropriate price,professional technical and after-sales service.
    LOG MACHINE,Be absorbed in good future!
    Download The E-catalog NowTailor Made 500 Ton Injection Molding Machine With Real Time Monitor
