Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment

Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment

    • Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment
    • Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment
  • Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 130S8 High Speed

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 30 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Transportation: Ocean Clamping Force: 1300KN
    Injection Weight: 149g Opening Stroke: 380mm
    Space Between Tie Bars: 410*410(mm*mm) Special: High Speed Thinwall

    Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment





    LOG-130S8 Injection Molding Machine



    1. The Characteristic Of LOG High Speed Special Injection Molding Machine



    ■ Higher Productivity

    Low Power Consumption

    Precision & Consistency

    Robust Construction



    Some of the important features :


    LCD computer control with big display screen
    Hydraulic double proportional valve
    Hard chrome plated high tensile strength steel tie bars
    Generous space for fitting large moulds
    Large opening stroke
    Two position transducers to control Clamping and Injection
    Four stages of injecting, independent velocity and pressure control
    Hydraulic mould height adjustment device
    Screw cold-start prevention device
    Melt decompression control
    Screw back pressure control
    Multiple hydraulic ejection
    Differential high speed clamping
    Centralized lubrication system
    Low pressure mould protection device

    Mechanical safety interlock
    Double electrical safety interlock

    Oil return filter
    Oil tank with inner stainless steel container



    Standard configuration :



    ■ Electronic ruler stroke control

    ■ Automatic lubrication system

    ■ Differential high pressure mold clamping

    ■ The independent nozzle temperature control

    ■ The oil temperature alarm device

    ■ Low pressure clamping protection device

    ■ High torque hydraulic motor

    ■ The servo motor and pump bigger power system

    ■ Mold-open and thimble linkage

    ■ Closed-loop control system



    Other Information :



    Oil treasure : Filter of hydraulic oil , good for pump and valves
    Long working life : Imported spare parts and updated version
    Aftersales service : Professional & timely

    Ceramic heating loop : Uniform heating, better thermal insulation properties so good for production
    Visiable lubrication system : On time clean , avoid cast steel parts abrasion and broken .



    Optional :



    ■ Widen the machine doors

    ■ Increase the mold space

    ■ Melt glue NC back pressure

    ■ Glass thermometer

    ■ Increase the injection Volume

    ■ Ceramic heating

    ■ The hydraulic safety insurance device

    ■ Longer nozzle

    ■ More air valve

    ■ More core pull



    2. LOG160S8 High Speed Machine Parameters



    INJECTION LOG130
    A B C
    Shot volume cm³ 181 263 302
    Shot weight (ps) G 149 239 274
    oz 5 8 10
    Max injection rate cm³/s 136.8 118 163
    Screw diameter Mm 38 42 45
    Plasticizing rate Kg/h 49 60 75
    Injection pressure Mpa 152 158 138
    Screw L:D ratio   24:1 20:1 18:1
    screw speed r/min 0~290
    CLAMPING
    Clamping force Kn 1300
    Opening stroke Mm 380
    Platen size MmXmm 610*610
    Space between tie bars MmXmm 410*410
    Mold thickness (Min--Max) Mm 150~430
    Hydraulic ejection stroke Mm 120
    Hydraulic ejection force Kn 42
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 15
    Heating capacity Kw 8.1
    Number of temp control zones   3+ 1(nozzle)
    GENERAL
    Dry-cycle time sec 4.0
    oil tank capacity L 210
    Machine dimensions Mxmxm 4.6*1.2*1.8
    Machine weight kg 3450



    3 . LOG-160S8 High Speed Machine Features:



    Thin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment





    LOG MACHINE insist to the idea of making high-end production line.will give you an optimum resolution.

    Download The E-catalog NowThin Wall High Speed Injection Moulding Machine , 130 Kn Plastic Injection Molding Equipment
