Product Details:

Place of Origin: Ningbo,China
Brand Name: LOG MACHINE
Certification: ISO9001:2008, SGS,CE
Model Number: 210A8

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: discussible
Packaging Details: Standard Export Package
Delivery Time: 25 Days
Supply Ability: 2000 Sets/Year
Detailed Product Description
Condition: New Clamping Way: Hydraulic & Mechanical
Clamping Force: 2100 Kn Energy Saving: Variable Pump
Computer: Easy To Operate Injection Unit: Double Cylinder
Color: Black&green&yellow Weight: 6500 Kg
Dimension: 5.4*1.32*2.1 Max Oil Pressure: 17.5

PID Temperature Control Variable Pump Injection Molding Machine 2100 Kn Rexroth System





LOG-210A8 Injection Molding Machine





1. Machine's Performance And Advantages:



Hydraulic System

1. YUKEN(Japan) / REXROTH (German) high response proportional variable displacement pump with automatically adjustable system pressure and flow.

2. Famous hydraulic components with high reliability and long service life.

3. Reasonably designed hydraulic valve block with little pressure loss.

4. Low noise.

5. By-pass filter-system to control contamination level under NAS8.

6. Energy-saving hydraulic system can reduce energy consumption by 25% to 50% compared with traditional fixed displacement pump system.

7. Low oil temperature system prolongs service life of the seals.



Clamping Unit

1. Integral plate structure of clamping tail platen and moving platen greatly enhances platen rigidity and reduces platen transformation.

2. Optimized toggle structure ensures stable mold opening and closing movement with little impact

3. The design of tail platen, moving platen and fixed platen are made by finite element analysis, which ensures rational stress distribution and high clamping precision.

4. Central lubrication system for mold height adjusting mechanism assures convenient machine maintenance.

5. Inspecting volume-type lubrication system guarantees high lubricating pressure and reliability.



Controlling System

1. Mirle MJ4700 computer controller from Taiwan.

2. 8" TFT LCD display.

3. Flexible molding data setting and adjusting.

4. 120 sets of mold data saving.

5. SPC production quality control.

6. PID temperature control.



2. LOG210A8 Machine Parameter



INJECTION LOG210
A B C
Shot volume cm³ 381 470 569
Shot weight (ps) G 347 429 520
OZ 12 15 18
Max injection rate cm³/s 133 165 200
Screw diameter Mm 45 50 55
Plasticizing rate Kg/h 82 117 141
Injection pressure Mpa 217 176 145
Screw L:D ratio   22:1 20:1 18:1
screw speed r/min 0~200
CLAMPING
Clamping force Kn 2100
Opening stroke Mm 480
Platen size MmXmm 745*745
Space between tie bars MmXmm 510*510
Mold thickness (Min--Max) Mm 200~550
Template maximum distance Mm 1030
Hydraulic ejection stroke Mm 150
Hydraulic ejection force Kn 67
Power Unit
Hydraulic system pressure Mpa 17.5
Pump motor Kw 18.5
Heating capacity Kw 13.1
Number of temp control zones   4+ (nozzle)
GENERAL
Dry-cycle time sec 4.5
oil tank capacity L 310
Machine dimensions Mxmxm 5.4*1.32*2.1
Machine weight Kg 6500



3. LOG210A8 Machine parts
