Product Details:

Place of Origin: Ningbo,China
Brand Name: LOG MACHINE
Certification: ISO9001:2008, SGS,CE
Model Number: 650A8

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: discussible
Packaging Details: Standard Export Package
Delivery Time: 50 Days
Supply Ability: 2000 Sets/Year
Detailed Product Description
Transportation: Ocean Injection Rate(cm³/s): 101
Clamping Force: 6500 Kn Energy Saving: Variable Pump
Computer: Easy To Operate Injection Unit: Double Cylinder
Color: Black&green&yellow Weight: 36000 Kg
Dimension: 9.6*1.9*2.3 Max Oil Pressure: 17.5

101 CM³ / S Variable Pump Injection Molding Machine 650T With Graphite Bush / Low Frictional Seals





LOG-650A8 Injection Molding Machine




1. LOG650A8 Machine features



Clamping unit

The new generation mold locking device and computer emulation optimized parameter makes motions of the moving plate,fixed plate and high rigidity toggle structure,the characteristic of high strength and anti-fatigue is secured.As compared with similar machines,it owns bigger internal spur between tie bars,mold space and mold opening stroke and may process plastic products of bigger size.



Computer controller

Professional injection moulding machine controller with software and hardware of industrial standard is convenient to expansion and revision of performance.

Adopting double CPU control makes high speed.

Mainly adopting PID control,the control accuracy reaches±1°.

Has the function of network management,improving efficency.



The injection unit

Short and forceful double-cylinder injection system is used to ensure the steady injection motion.The strain free fixed mold plate and screw assembly with optimized design help to reach better plasticing capacity and effect.PID temperature control regulate the speed and pressure of injection,pressure keeping,smelting,back pressure and other motions to ensure the quality of formed products and continuation of production.Auto material preparation,drooling proof,and anti cold start lapse functions ensure the high efficent,simple and safe operations.



The hydraulic unit

High efficiency,energy-saving and high precise proportional pressure and flow variable displacement pump system make the out of the hydraulic system matching the required power for entire machine operation without loss of high pressure throttle and overflow energy.As comparedwith constant displacement pump,it saves power by 30%~60%.A motor with same power may be fitted with an oil pump of bigger displacement and thus accelerates the speed of machine.Besides,the low oil temperature will prolong the service life of sealing elements.

Buffer device is used in every mold opening and clamping oil way to ensure steady mold opening and clamping operation without any impact.Besides,differential mold clamping operation is fitted to ensure high production efficiency.


2. LOG650A8 Machine Parameter



INJECTION LOG650
A B C
Shot volume cm³ 2160 2734 3376
Shot weight (ps) G 1966 2488 3072
OZ 67 87 108
Max injection rate cm³/s 420 531 656
Screw diameter Mm 80 90 100
Plasticizing rate Kg/h 254 340 442
Injection pressure Mpa 215 170 138
Screw L:D ratio   22:1 21:1 19:1
screw speed r/min 0~140
CLAMPING
Clamping force Kn 6500
Opening stroke Mm 920
Platen size MmXmm 1320*1320
Space between tie bars MmXmm 930*900
Mold thickness (Min--Max) Mm 350~910
Template maximum distance Mm 1830
Hydraulic ejection stroke Mm 265
Hydraulic ejection force Kn 182
Power Unit
Hydraulic system pressure Mpa 17.5
Pump motor Kw 22+30
Heating capacity Kw 38.3
Number of temp control zones   6+ (nozzle)
GENERAL
Dry-cycle time sec 6
oil tank capacity L 1500
Machine dimensions Mxmxm 9.6*1.9*2.3
Machine weight kg 36000


3. LOG650A8 Machine parts
