Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine

Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine

    • Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine
    • Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine
  • Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 300S8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 45 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Transportation: Ocean Clamping Force: 3000KN
    Injection Weight: 673~980g Opening Stroke: 570mm
    Space Between Tie Bars: 610*590(mm*mm) Energy Saving: Servo

    Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine



    LOG-300S8 Injection Molding Machine


    1LOG Injection Molding Machine Details



    The Injection Units
    Short and forceful double-cylinder injection system is used to ensure the steady injection motion. The strain free fixed mold plate and screw assembly with optimized design help to reach better plasticing capacity and effect. Auto material preparation,drooling proof, and anti cold start lapse functions ensure the high efficent, simple and safe operations.

    The Clamping Parts
    ● Ejection system designed according to Euromap 2/3, ejector rod changing is more flexible: Ejection position can be adjusted with using adjustable stopper. All equipment is equipped with European ejector design, and the ejector can be replaced at any time. Coordinated with the adjustable ejector reset device, the reciprocating position of the ejector can be adjusted at will.
    ● Strict QC system ensures the machine with best clamping precision when delivered.
    ● The highly adjustable movable platen sliding feet make the loading of the movable platen can be more even distributed; hence the tie bar loading deformation is reduced to ensure the guiding precision.

    Some of the important features:

    ● Highly optimized servo-hydraulic technology, with improved efficiency for lower energy consumption.
    ● Optimized clamping unit provides lower energy consumption and faster movements for reduced cycle times.
    ● Fixed platen with centralized force loading and less platen flexing. Redesigned moving platen providing centralized force distribution from the toggle system to the mold. The result: higher rigidity and stability.



    2. Parameter of LOG300S8 Machine



    INJECTION LOG300
    A B C
    Shot volume cm³ 740 929 1077
    Shot weight (ps) G 673 845 980
    oz 24 30 34
    Max injection rate cm³/s 262 330 382
    Screw diameter Mm 58 65 70
    Plasticizing rate Kg/h 120 150 185
    Injection pressure Mpa 190 151 130
    Screw L:D ratio   22:1 22:1 20:1
    screw speed r/min 0~150
    CLAMPING
    Clamping force Kn 3000
    Opening stroke Mm 570
    Platen size MmXmm 870*850
    Space between tie bars MmXmm 610*590
    Mold thickness (Min--Max) Mm 200~600
    Hydraulic ejection stroke Mm 160
    Hydraulic ejection force Kn 77
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 22
    Heating capacity Kw 18
    Number of temp control zones   5+ (nozzle)
    GENERAL
    Dry-cycle time sec 5.0
    oil tank capacity L 380
    Machine dimensions Mxmxm 6.4*1.6*2.18
    Machine weight kg 9100


    3. Machine Products


    Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine

    4. The Machine Parts



    Mechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine



    Download The E-catalog NowMechanical Plastic Basket Making Machine , 3000KN Horizontal Injection Moulding Machine



    Here are the right price, first-class quality, professional technical and after-sales service.
    LOG MACHINE, Be absorbed in good future!
