Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G

Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G

    • Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G
    • Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G
  • Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 320S8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 45 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Transportation: Ocean Clamping Force: 900KN
    Injection Weight: 106~170g Opening Stroke: 320mm
    Space Between Tie Bars: 360*360(mm*mm) Energy Saving: Servo

    Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G





    LOG-320S8 Injection Molding Machine



    1LOG Injection Molding Machine Details

    ■ Computer Controller PLC
    Professional injection moulding machine controller with software and hardware of industrial standard is convenient to expansion and revision of performance.
    Adopting double CPU control makes high speed.
    Mainly adopting PID control, the control accuracy reaches±1°.
    Has the function of network management, improving efficency.
    ■ The Mould Adjusting Units
    The automatic mold adjusting device driven by hydraulic motor adopts gear coupling drive, features steadiness, high-efficiency and saving mold loading time.
    ■ Servo energy-saving system

    Using the servo motor oil esectriciyt composite sturcture, high response, low noile and excellent

    electricity -saving performance.



    Some of the important features:

    Clamping system: Faster response, steable and high rigidity

    Injection system: Accurate and flexible, lower rejection rate

    Control system: Computer and simple operation, molding data memory system

    Power system: Energy saving, high efficient and precise



    LOG can provide our clients with general-purpose screws to meet the diverse requirements, but also for different types of plastics and processing characteristics of the product, Konger offer special types of screws to meet high qualiy and high precision requirment.

    Such as: UPVC, MPPA, PA, PC, CP, PPS, PET and other special screw.


    2. Parameter of LOG320S8 Machine

    INJECTION LOG320
    A B C
    Shot volume cm³ 1062 1231 1414
    Shot weight (ps) G 966 1120 1286
    oz 34 39 45
    Max injection rate cm³/s 313 362 416
    Screw diameter Mm 65 70 75
    Plasticizing rate Kg/h 170 210 240
    Injection pressure Mpa 175 152 133
    Screw L:D ratio   22:1 21:1 19.6:1
    screw speed r/min 0~170
    CLAMPING
    Clamping force Kn 3200
    Opening stroke Mm 615
    Platen size MmXmm 945*945
    Space between tie bars MmXmm 660*660
    Mold thickness (Min--Max) Mm 250~670
    Max.daylight Mm 1285
    Hydraulic ejection stroke Mm 160
    Hydraulic ejection force Kn 77
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 30
    Heating capacity Kw 21.5
    Number of temp control zones   5 +(nozzle)
    GENERAL
    Dry-cycle time sec 5.0
    oil tank capacity L 500
    Machine dimensions Mxmxm 6.8*1.63*2.25
    Machine weight kg 12500



    3. Machine Injection Unit

    Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G



    4. Main Unit

    Hydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G

    LOG MACHINE, Be absorbed in good future!

    Download The E-catalog NowHydraulic Toggle Type Injection Moulding Machine 320 Ton Injection Weight 1120G
