27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine

27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine

    • 27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine
    • 27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine
    • 27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine
    • 27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine
  • 27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 250A8 PPMA

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 45 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Computerized: Computerized Transportation: Ocean
    Clamping Force: 2500KN Injection Weight: 464~785g
    Opening Stroke: 520mm Space Between Tie Bars: 560*530(mm*mm)
    Special: Special For PPMA

    27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine





    LOG-250A8 PPMA Injection Molding Machine



    1. LOG A8 Series Configuration Table:



    Injection Unit

    ■ Double cylinder injection system

    ■ Antifatigue , anti-corrosive screw and barrel

    ■ Multi stages of speed , pressure and position for injection hold on and charge

    ■ Postion or time hold on changeover

    ■ Screw position transducer control

    ■ To prevent the screw cold start function

    ■ Low speed high torque screw drive motor

    ■ Close loop barrel temperature control

    ■ The nozzle centre adjusting device

    ■ Screw rpm show

    ■ Stainless steel hopper

    ■ Barrel feed opening cooling



    Clamping Unit

    ■ Diagonal row within five hinge type hyperbolic clamping mechanism

    ■ Transducer for mold open and close position

    ■ Mechanical safety device

    ■ Multi stage of mold open/close speed , pressure  and position

    ■ Rapid differential clamping system

    ■ Automatic mold height adjustment

    ■ Low pressure mold protection

    ■ Box model platen: T slots

    ■ Auto centralized lubrication system



    Hydraulics System

    ■ Propoffional pressure and speed control

    ■ Oil suck filter

    ■ Oil temperature control and alarm

    ■ By-pass oil filter



    2. The Characteristic of PPMA Special Machine:



    ■ Save more than 30% energy than conventional machinesHigh-speed variable pump hydraulic system configuration

    ■ PPR Double helix screw

    ■ Temperature control air cooling device for each separate Cylinder to make the high precision temperature control

    ■ Two hydraulic core pull device



    3. Our Services:

    We can according to your detailed production requirements to design and recommend the best suitable machine to you, such as ( product materials, sizes & weights, production quantity per hour) .
    Our professional service team will give you technology and production support, which can avoid loss and save time.



    4. LOG250A8-PPMA Machine Parameters:



    INJECTION LOG250
    A B C
    Shot volume cm³ 510 687 863
    Shot weight (ps) G 464 625 785
    OZ 16 22 27
    Max injection rate cm³/s 175 236 297
    Screw diameter Mm 50 58 65
    Plasticizing rate Kg/h 103 139 174
    Injection pressure Mpa 224 166 132
    Screw L:D ratio   24.1;1 21:1 18.7:1
    screw speed r/min 0~180
    CLAMPING
    Clamping force Kn 2500
    Opening stroke Mm 520
    Platen size MmXmm 820*790
    Space between tie bars MmXmm 560*530
    Mold thickness (Min--Max) Mm 200-580
    Max.daylight Mm 1100
    Hydraulic ejection stroke Mm 150
    Hydraulic ejection force Kn 67
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 22
    Heating capacity Kw 16
    Number of temp control zones   4+ (nozzle)
    GENERAL
    Dry-cycle time sec 4.8
    oil tank capacity L 380
    Machine dimensions Mxmxm 6.2*1.46*2.15
    Machine weight kg 8000



    5. The PPMA Machine:



    27 OZ Hydraulic Injection Molding Machine , 2500 KN Plc Injection Moulding Machine



    Here are the right price , first-class quality, professional technical and after-sales service.
    LOG MACHINE, Be absorbed in good future!
