Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN

Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN

    • Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN
    • Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN
  • Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN

    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 1100A8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 90 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Transportation: Ocean Clamping Force: 11000KN
    Injection Weight: 3751~6340g Opening Stroke: 1150mm
    Space Between Tie Bars: 1150*1100(mm*mm) Special: Special For Garbage Can

    Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN





    LOG-1100A8 Injection Molding Machine For Garbage Can



    1. The Characteristic Of LOG-1100A8 Garbage Can Injection Molding Machine



    ■ The Injection Units

    •  New screw design with better plasticizing and mixing effect.
    •  Modular structure design for convenient components replacement.
    •  Screw L/D ratio of over 20:1 for better plasticizing effect.
    •  Central lubrication device of injection unit assures convenient machine maintenance.
    •  Slider under movable hopper for easier materials feeding.
    •  A variety of optional special screws for specific materials.

    The Clamping Parts

    The new generation mold locking device and computer emulation optimized parameter makes motions of the moving plate, fixed plate and high rigidity toggle structure, the characteristic of high strength and anti-fatigue is secured. As compared with similar machines, it owns bigger internal spur between tie bars, mold space and mold opening stroke and may process plastic products of bigger size.

    Computer Controller PLC

    Professional injection moulding machine controller with software and hardware of industrial standard is convenient to expansion and revision of performance.

    Adopting double CPU control makes high speed.

    Mainly adopting PID control,the control accuracy reaches±1°.

    Has the function of network management,improving efficency.

    ■ The Hydraulic Units

    • YUKEN(Japan) high response proportional variable displacement pump with automatically adjustable system pressure and flow.
    • Famous hydraulic components with high reliability and long service life.
    • Reasonably designed hydraulic valve block with little pressure loss.
    • Low noise.
    • Energy-saving hydraulic system can reduce energy consumption by 25% to 50% compared with traditional fixed displacement pump system.
    • Low oil temperature system prolongs service life of the seals.



    Machine Features:
    ■ Special PE screw & barrel is good for fast charging speed and mixed color effect.
    ■ Upgraded hydraulic system can improve the injection and charging speed.
    ■ Improved frame structure is more suitable for Garbage Can making requirements.
    ■ The product can automatically drop out from the customized slider, that improves the production efficiency.



    2. LOG1100A8 Garbage Can Injection Molding Machine Parameters



    INJECTION LOG1100
    A B C D
    Shot volume cm³ 4123 4989 5938 6968
    Shot weight (ps) G 3751 4540 5403 6340
    OZ 133 161 191 225
    Max injection rate cm³/s 702 850 1010 1186
    Screw diameter Mm 100 110 120 130
    Plasticizing rate Kg/h 378 503 600 767
    Injection pressure Mpa 220 182 153 130
    Screw L:D ratio   22:1 22:1 20.2:1 18.6:1
    screw speed r/min 0~120
    CLAMPING
    Clamping force Kn 11000
    Opening stroke Mm 1150
    Platen size MmXmm 1650*1650
    Space between tie bars MmXmm 1150*1100
    Mold thickness (Min--Max) Mm 450~1200
    Hydraulic ejection stroke Mm 350
    Hydraulic ejection force Kn 270
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 45+45
    Heating capacity Kw 68.48
    Number of temp control zones   6+ (nozzle)
    GENERAL
    Dry-cycle time sec 10
    oil tank capacity L 2300
    Machine dimensions Mxmxm 12.5*2.8*3.5
    Machine weight kg 60000


    3. LOG1100A8 Garbage Can Injection Molding Machine Instructions:



    Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN





    4. A8  series Components



    Thermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN









    Download The E-catalog NowThermoplastic Fully Automatic Injection Moulding Machine Clamping Unit 11000 KN



    LOG injection molding machine---tailor-made meet all your requirements
