    Product Details:

    Place of Origin: Ningbo,China
    Brand Name: LOG MACHINE
    Certification: ISO9001:2008, SGS,CE
    Model Number: 650S8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Packaging Details: Standard Export Package
    Delivery Time: 30 Days
    Supply Ability: 2000 Sets/Year
    Detailed Product Description
    Structure: Horizontal Plasticizing Way: Screw Type
    Automation: Automatic Clamping Way: Hydraulic & Mechanical
    Computerized: Computerized Transportation: Ocean
    Clamping Force: 6500KN Injection Weight: 1966~3072g
    Opening Stroke: 920mm Space Between Tie Bars: 930*900(mm*mm)

    Automated Toggle Stable High Performance Injection Molding Machine





    LOG-650S8 Injection Molding Machine



    1. Characteristic



    . Strengthen locking structure

    Optimized special locking system to reach efficient and fast production

    . Professional templates optimized design

    Template by advanced finite element analysis software to optimize design, high rigidity, high strength, to meet the rapid impact conditions demand.

    . Centralized lubrication, reliable protection

    Configuring rational centralized lubrication, providing more professional, better lubrication to make machine more cleaner.

    . New type screw driving system

    Spline connection for screw and oil motor, smooth and reliable transmission, big transfer torque, easy disassembly.

    . Powerful, friendly control system

    Adopts professional controller and friendly interface, easy and fast operation, with good reliability.

    . Excellent injection performance

    Double cylinder injection, entire floor-guided, reliable and stable.

    . Superior clamping system

    Adopts optimized connection rod structure, faster and smoother operation.

    . New frame structure

    Simple and generous appearance, machine body force reasonable and stronger.

    . Professional plasticizing system

    Suitable for different types of plastic raw material with professional plasticizing and heating system, good plasticizing performance.

    . High efficient powerful servo system optional

    Power system adopts high pressure gear box and servo motor, rotary encoder, pressure transducer and servo amplifier to get system closed-loop control.



    Optional:



    More core pull

    More air valve

    Glass thermometer

    The hydraulic safety insurance device

    Increase the mold space

    Widen the machine doors

    Ceramic heating

    Melt glue NC back pressure

    ■ Increase the injection quantity



    2. LOG650S8 Machine Parameter



    INJECTION LOG650
    A B C
    Shot volume cm³ 2160 2734 3376
    Shot weight (ps) G 1966 2488 3072
    oz 67 87 108
    Max injection rate cm³/s 420 531 656
    Screw diameter Mm 80 90 100
    Plasticizing rate Kg/h 254 340 442
    Injection pressure Mpa 215 170 138
    Screw L:D ratio   22:1 21:1 19.5:1
    screw speed r/min 0~140
    CLAMPING
    Clamping force Kn 6500
    Opening stroke Mm 920
    Platen size MmXmm 1320*1290
    Space between tie bars MmXmm 930*900
    Mold thickness (Min--Max) Mm 350~910
    Hydraulic ejection stroke Mm 265
    Hydraulic ejection force Kn 182
    Power Unit
    Hydraulic system pressure Mpa 17.5
    Pump motor Kw 22+30
    Heating capacity Kw 38.3
    Number of temp control zones   6+ (nozzle)
    GENERAL
    Dry-cycle time sec 6
    oil tank capacity L 1500
    Machine dimensions Mxmxm 9.6*1.9*2.3
    Machine weight kg 36000
